Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels

    Buy cheap Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels from wholesalers

    Buy cheap Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels from wholesalers
    • Buy cheap Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels from wholesalers
    • Buy cheap Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels from wholesalers
    • Buy cheap Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels from wholesalers

    Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels

    Ask Lasest Price
    Brand Name : NANTE
    Model Number : Alloy Steel Crane Wheels
    Certification : ISO9001, CE, CCC
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 Piece/Pieces per Year
    Delivery Time : Within 14 days
    • Product Details
    • Company Profile

    Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels

    Quick Details

    • Place of Origin: Zhejiang, China (Mainland)
    • Brand Name: Nante
    • Model Number: 350
    • Usage: crane long travel
    • Material: carbon steel, alloy steel
    • Weight: 40~250Kg

    Packaging & Delivery

    Packaging Details:Seaworthy packing into container or bulk vessel
    Delivery Detail:Based on client's needs

    Detailed Product Description

    Heavy Industrial Alloy Steel Hoist End Beam for Crane

    • Usage: crane long travel
    • Material: carbon steel, alloy steel
    • Weight: 40~250Kg
    • Lead time: 10~40 days

    Crane wheel, crane forging wheels for port container crane, steel crane wheel, steel crane wheels for crane, tubeless crane wheel, railway steel crane wheels, heavy duty crane wheels, forged crane wheel, Un-mounted Steel Crane Wheels, Steel Casting Crane Wheel, steel crane wheels, wheel hub forging for lifter or crane, Best steel forging crane wheels, high quality crane wheel.


    • Manufactured from fine gain, fully killed, vacuum degassed forged medium carbon steel
    • Heat treated using our in house processes to provide a uniform contour hardness in the tread and inner flange wear surfaces, while maintaining a ductile core to resist shock loads
    • Resistant to flange fracture or wear
    • Designed to resist pitting and spalling

    Heavy Industrial Alloy Steel Hoist End Beam / Crane Wheel / Crane Forging Wheels
    description:


    Crane wheels are replaced because of flange wear, flange breakage, and mechanical overloads characterized by pitting and spalling. Each of these in-service factors must be carefully considered before the combination of wheel design, material selection, hardness pattern and heat treating technology is selected.

    That's why every Xtek hardened steel crane wheel is specially designed and heat treated to maximize its resistance to the damaging forces at work in heavy industrial applications.


    Advantages:


    • Reduce maintenance cost of your wheels and wheel assemblies
    • Improve the life of your rail
    • Provide an additional 40% load carrying capability over rim toughened wheels
    • Delivery in 6-8 weeks, less when required
    • Very high degree of hardness with good depth of the treated area.
    • High wear resistance.
    • Excellent impact resistance

    Applications:


    • Overhead cranes
    • Gantry and portal cranes
    • Transfer cars

    specification parameter

    NO.

    Item

    Drg.NO

    Size(mm)

    Weight

    D(h9)

    D1

    B

    B1

    A

    h

    h1(h11)

    b1(H9)

    d(S6)

    I

    d4

    L

    L1

    G

    b2

    1

    Active wheel group
    Φ250

    L754

    250

    280

    90

    70

    180

    180

    80

    30

    45

    82

    M20

    237

    130

    485

    14

    45

    2

    Passive wheel group
    Φ250

    L755

    250

    280

    90

    70

    180

    180

    80

    30

    -

    -

    M20

    -

    130

    -

    -

    42

    3

    Active wheel group
    Φ350

    L756

    350

    380

    100

    81

    200

    225

    105

    50

    65

    105

    M20

    320

    150

    69

    18

    112

    4

    Passive wheel group
    Φ350

    L757

    350

    380

    100

    81

    200

    225

    105

    50

    -

    -

    M20

    -

    150

    -

    -

    105

    5

    Active wheel group
    Φ400

    L758

    400

    440

    120

    100

    240

    260

    120

    50

    80

    130

    M20

    365

    170

    85

    22

    155

    6

    Passive wheel group
    Φ400

    L759

    400

    440

    120

    100

    240

    260

    120

    50

    -

    -

    M20

    -

    170

    -

    -

    148

    7

    Active wheel group
    Φ500

    L762

    500

    540

    130

    110

    270

    300

    140

    50

    80

    130

    M20

    365

    195

    85

    22

    250

    8

    Passive wheel group
    Φ500

    L763

    500

    540

    130

    110

    270

    300

    140

    50

    -

    -

    M20

    -

    195

    -

    -

    245

    9

    Active wheel group
    Φ315

    L774

    315

    345

    100

    81

    200

    225

    105

    50

    65

    105

    M20

    320

    150

    69

    18

    112

    10

    Passive wheel group
    Φ315

    L775

    315

    345

    100

    81

    200

    225

    105

    50
