New Electric Chain Hoist 250KG European Type with Double Hook Insulation Grade F for Industrial Lifting

Brief Description:

Composed by cable reel, wire rope, electric motor, brake, pendant/remote and other components, the electric hoist has such characteristics as compact structure, easy installation, low cost and so on, which can be widely used in workshop, factory and other place to lift heavy load.

Features of European electric chain hoist :
1. Gearbox---Maintenance-free.working-level for M6.BM electric chain hoist with a rated service life of 1990full load hours.In practical terms.this means the service life is extended by approx.20%.the helicalgearling inside the gearbox also reduces operating noise and provide smooth operation

2. Brake----Maintenance-free.because of minimum wear.adjustment is not necessary.The brake is enclosed in enclosed in the electrical panel and provides double protection from the elements

3. Slip cluthch---Maintenance-free.Integrated begind the brake in the power drive.it provides reliable protection against overload.Integrated slip clutch monitoring prevents premanent demage to the slip clutch

4. Height adjustable control pendanl cable----The length of the control cable.
Therefore.the suspension height of the control pendant can be infinitrly varied for a hook path range of 2-5mand 5-8m.The excess control cable is accommodated behind the service cover

5. Control---24V contactor control.operating limit switches
(upper/lower)

6. Steel chain---A special Brima chain of high-strength.Hardened age-resistant material.Galvanized and other suface-treatments are available to protect against specific hostil environments

7. Suspension bracket----BM hoists are supplied with short and long suspension brackets as standard and can always be attached to the super-structure with the optimal connectin

8. Housing---Robust and lightweight die-cast aluminium housing of compact and modern industrial design.Automtive paint.to provide more long-term protection

9. Hoist motor---High-performance motor with large safety reserves even at high ambient temperatures and in prolonged operation.Using 2 hoist speed with 1:4 speed ratio and frequency Control to multi-speed requirements

10. Chain drive---The unit is a complete assembly consisting of the chain and chain guide which facilitates quick and easy replacement of the entire chain drive without having to remove the otor or gear parts.Downtime can therefore be reduced significantly.The chain drive consists of highly wear-resistant materials for long service life

11. Chain collector box---Suspended from a pivoting connection,is made of tough,flexible and particularly impact-presistant plastic;capacity for up to 8m hook path ,A flexible chain container for chain lengths up to 40m as well as special lengths up to 120m

12. Bottom block---Comfortable hook device by hand For improved ergonomic handling of the hook. The hook after forging processing to make great-strength,hooks rotate by 360 degrees,a specially designed safety tongue,to ensure safe operetion.

Technical specifications:

    Nante Machinery is a subsidiary company of Zhejiang Zhongjian Road & Bridge Machinery Co, . LTD.

    We have 25 years experience in lifting equipment manufacturing.Four production bases and two R&D Centers covers an area of morethan 100, 000 square meters, and above 400+ skilled employees, among which, a rough 10% are engineers. Our production lines are all equipped with world-leading brand tools and devices.

    In recent years, our annual revenue has steadily exceeded 80 million USD, in which  20% are contributed from oversea market. We have established long term business relationship with lots of clients from USA, Singapore, Indonesia, Kenya, India, Cambodia, South Africa, Albania, Chile etc.

    As a mature heavy machinery manufacturer, we not only produce individual industrial equipments, but also deliver an end-to-end solution to cover the entire project lifecycle including machinery design, manufacturing, installation and on-going maintenance. We have more than 50 models of products, which can be divided into five major categories as following:

1. Series of construction cranes

Bridge launching crane, form traveller, bridge deck launching gantry, tower crane etc.

2. Series of workshop, shipyard, and port cranes

overhead crane, gantry crane, jib crane and portal crane etc.

3. Various parts of cranes

Electric hoist, winch, motors, rails, bus bars etc.

4. Structural steel projects

Contractor of industrial steel structures such as new-built workshops, towers, chutes, etc

5. Steel Bailey bridges

Two standard models called Compact 100 and 200 in International market

    Quality concept lies deeply in our blood:

1. Passed ISO9001:2008 Quality Management System

2. Holder of Class A License of Manufacturing and Repairing of China Specialized Equipments.

3. Member of China Construction Machinery Association.

4. China AAA Credit Company

5. ZHEJIANG Top Brand and Trade Mark

    Fact is always more persuading than paper works. We Design and Build Chinese highest truss gantry crane, longest beam launcher and Drafter Chinese beam launcher national standard.

    We pursue the value of professional, innovation, integrity and win-win in our company’s long term development strategy. We target to become one of China’s top manufacturer and solution provider in the heavy machinery industry and a competitive player in the overseas market.
